MS-C2966-X12RGOPC-868M AIOT-2MP-12X-LORAWAN

Name: MS-C2966-X12RGOPC-868M AIOT-2MP-12X-LORAWAN
Brand: Milesight
SKU: 10893095
Price: 988.10 EUR
Availability: OutOfStock

988,10 €

Producto Disponible (Stock en camino) - (Imp. Incluidos)

Costes de envío Ver descripción

Marca: Milesight • Peso: 1,75 Kg

Cámara IP 5G AIoT 12X Pro Bullet Plus. Puerta de enlace LoRaWAN® integrada

2MP · IA · 5G · Zoom óptico 12X · Super WDR Pro 3 en 1 · Sensor de luz estelar STARVIS de 1/1,8" · Luz ultra baja de 0,002 lux · 100 fps · IP67 · Protección contra sobretensiones de 4KV · Smart IR II · IR de 180 m Distancia · P2P · PoE

* Puerta de enlace LoRaWAN® integrada

* Admite conexión con ≥ 2000 sensores / nodos LoRaWAN®

* Recepción de datos de 8 dispositivos finales simultáneamente

* Admite IoT, 5G/4G/3G, P2P, Nano SIM

* Admite PoE, tarjeta SD, hasta 256G; Diseño de 3 ejes

* IP67 solo para el cuerpo de la cámara

Categoría: - 5G AIoT Series | Tags: | Comentarios

Rendimiento excepcional de LoRa

La cámara utiliza el último chip Semtech LoRa y una CPU de cuatro núcleos de 64 bits para admitir la recepción de datos de hasta 8 dispositivos finales al mismo tiempo, maneja más tráfico con menos consumo de energía y tiene una línea de visión de alrededor de 15 km en área abierta, haciéndolo ideal para una variedad de aplicaciones.

Amplia extensibilidad 5G

Impulsada por la tecnología 5G y AI, la cámara Milesight 5G AIoT Pro Bullet Plus tiene una función de conectividad enriquecida para una flexibilidad y escalabilidad sin igual. En comparación con la videovigilancia tradicional, la videovigilancia inteligente amplía el alcance de la vigilancia de la seguridad, brindando nuevas posibilidades para industrias como Smart City, Smart Retail, Smart Medical, Smart Transportation y otros campos.

Camera	Name	2MP 5G AIoT 12X Pro Bullet Plus Network Camera
	Image Sensor	1/2.8" Progressive Scan CMOS
	Min. Illumination	Color: 0.002Lux @F1.2, Color: 0.005Lux @F1.6, B/W: 0Lux with IR on
	WDR	140dB Super WDR (Super WDR Pro is optional for T Series)
	Shutter Time	1/100000s∼1s
	Day/Night Mode	Day/Night/Auto/Customize/Schedule
	IR Distance	Up to 180m
	S/N	>55dB
	Lens	Lens	5.3~64mm, 12X Optical Zoom
Field of View		H61°~H5°/D69°~D5°/V36°~V2°
Mount		Φ14
Focus Control		Auto/Manual
Aperture		F1.6~F2.8
Iris Control		Auto
Video		Max. Image Resolution	1920x1080
	Frame Rate	60Hz: 100fps@(1920x1080)(Optional for T Series), 60fps@(1920x1080, 1280x960, 1280x720, 704x576) 50Hz: 100fps@(1920x1080)(Optional for T Series), 50fps@(1920x1080, 1280x960, 1280x720, 704x576)
	Secondary Stream	60Hz: 60fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180) 50Hz: 50fps@(704x576, 640x480, 640x360, 352x288, 320x240, 320x192, 320x180)
	Tertiary Stream	60Hz: 30fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x180) 50Hz: 25fps@(1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240, 320x192, 320x180)
	Video Compression	H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
	Video Bit Rate	16Kbps∼16Mbps (CBR/VBR adjustable)
	Privacy Masking	Up to 28 areas(24 mask areas and 4 mosaic areas)
	ROI	Up to 8 areas
	Image Settings	Saturation/Brightness/Contrast/Sharpness
	Web Access	Support IE/Firefox/Chrome/Safari Browser
	Audio	Audio Compression	G.711/AAC/G.722/G.726
Audio Sampling Rate		8/16/32/44.1/48KHz
Audio Bit Rate		16~256kbps
Two-way Audio		Support
Interface		Ethernet	1*RJ45 10M/100M Ethernet Port
	Audio I/O	1/1
	Alarm I/O	1/1
	Mobile Communication Parameter	Wireless Communication	Support 5G/4G/3G
Frequency Bands		5G NR: n1/n2/n3/n5/n7/n8/n12/n20/n28/n41/n66/n71/n77/n78/n79 LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B14/B17/B18/B19/B20/B21(TBD)/ B25/B26/B28/B29/B30/B32/B66/B71 LTE-TDD: B34/B38/39/B40/B41/B42/B48 LAA: B46 WCDMA: B1/B2/B3/B4/B5/B6/B8/B19
Wireless Transmission Speed		SA: DL 3.3Gbps; UL 250Mbps NSA: DL 3.4Gbps; UL 200Mbps LTE: DL 2.0Gbps; UL 150Mbps WCDMA: DL 42Mbps; UL 5.76Mbps
SIM Card		Nano SIM
LoRaWAN®		Antenna	1*50ΩSMA-Female External Antenna Connector
	Channel	8 channels simultaneously
	Demodulation	1Mhz
	Frequency Band	CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923
	Sensitivity	-140dBm Sensitivity @292bps
	Output Power	27dBm Max
	Protocol	V1.0 Class A/Class B/Class C and V1.0.2 Class A/Class B/Class C
	Communication Range	15km
	Network	Network Storage	NAS(Support NFS, SMB/CIFS), ANR
Network Protocols		IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, Bonjour, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL
Intelligent Analytics		Video Analysis	Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed
	Face Detection	Detect and capture faces, get real-time snapshots
	People Counting& Report	Count the number of people entering or exiting, up to 4 detection areas for regional people counting
	System	Storage	Support microSD/SDHC/SDXC Card Local Storage, up to 256G
Advanced Function		BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, EIS, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark
SIP/VoIP Support		Yes, Voice&Video-over-IP
Event Trigger		Motion Detection, Network Disconnection, External Input, Audio Alarm, etc.
Event Action		FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc
System Compatibility		ONVIF Profile G & Q & S & T, API
General		Working Temperature	-40℃∼60℃
	Working Humidity	0∼90%(Non-condensing)
	Power Supply	PoE (802.3at) / DC 12V±10%
	Power Consumption	10W MAX, 16W MAX (With IR on)
	Surge Protection	4KV
	Weather Proof	Up to IP67-rated for Weather-resistant Performance (Only for camera body)
	Dimensions	320mmX134mmX126mm, 320mmX134mmX292mm (With 5G Antennas)
	Weight	1608g
	Warranty	3/5 Years

MS-C2966-X12RGOPC-868M AIOT-2MP-12X-LORAWAN

988,10 €
